39' Static Lattice Jib, Offsettable at 0°, 20° and 40°,
80 Metric Ton and 100 US Tons,
Main and Auxiliary Winches with 18mm Wire Rope,
Electronic load indicator with digital read-out for hook load, rated load, boom length, boom angle, load radius, analog display to indicate the capacity utilization. Limit switches on hoist and lowering motions, pressure-relief and safety holding valves,
17,600# Counterweights in sections of 11,250#, 3,750# and 2,650# (15,000# fitted on superstructure, 2,650# hydraulically stowed on carrier deck),
Hook Block,
Operator's cab cab tiltable up to 18°,
9' wide wide 8 x 6 x 6 Carrier with 2-man driver’s cab,
Daimler Chrysler diesel engine - SUBJECT TO FINAL CONFIRMATION,
Allison automatic transmission, transfer case with off-road range - SUBJECT TO FINAL CONFIRMATION,
Air Conditioning UP and Down,
Front and Rear Tires: 14.00 R 25 on 11.25-25 rims; tubeless road-tread tires, all axles single-wheeled - SUBJECT TO FINAL CONFIRMATION,
Hydropneumatic suspension, all axles hydraulically blockable,
Shortest 4-axle machine in its category,
Four hydraulically telescoping outrigger beams with hydraulic jack legs.
Location
India
Crane Details
Boom/Jib
Boom/Jib Images
Boom:
Boom: 35.8' - 164' Six Section Full Power Boom Boom Length: 164'
Jib:
Jib: 39' Static Lattice Jib Jib Length: 39'
Boom/Jib Notes:
35.8' - 164' Six Section Full Power Boom,
39' Static Lattice Jib, Offsettable at 0°, 20° and 40°,
Carrier
Carrier images
Carrier: 9' wide wide 8 x 6 x 6 Carrier Mileage:
Carrier Notes:
9' wide wide 8 x 6 x 6 Carrier with 2-man driver’s cab,
Daimler Chrysler diesel engine - SUBJECT TO FINAL CONFIRMATION,
Allison automatic transmission, transfer case with off-road range - SUBJECT TO FINAL CONFIRMATION,
Air Conditioning UP and Down,
Front and Rear Tires: 14.00 R 25 on 11.25-25 rims; tubeless road-tread tires, all axles single-wheeled - SUBJECT TO FINAL CONFIRMATION,
Hydropneumatic suspension, all axles hydraulically blockable,
,
,
