CranesList Comprehensive Crane Listing

All Terrain

2001 Grove GMK5210

CLEAN ONE OWNER CRANE!
$265,000

CranesList ID: 993

All Information Provided By The Seller

Crane Specifications

Overview


Year: 2001
Make: Grove
Model: GMK5210
Crane Type: All Terrain
Serial:
Tons: 210
Weight: 134,540#
Location: New Mexico
Price: $265,000
CranesList ID: 993
Good Condition

Notes

  • 44’-197’ Six Section Full Power Boom with maximum height of 207',
  • Twin Lock Boom Pin Section,
  • 43'-72' Bifold Hydraulic Swingaway Lattice Offsetable (5° - 40°) Jib,
  • 2 - 26' Jib Inserts for a total of 125' of Jib,
  • Main and Auxiliary Winches with 22mm Wire Rope,
  • Drum Rotation Indicator, 2 Speed, Load Moment Indicator with Anti-Two Block,
  • Cummins 6BTA 5.9-C 6 Cylinder Diesel Engine (Upper) - AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • Hook Block,
  • 138,800# Total Counterweight, AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • 10' wide Grove Carrier With 10 x 8 x 10 5 Axle Drive/Steer,
  • Cummins 600 water cooled 6 Cylinder turbo charged and after cooled Diesel Engine - AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • Allison Automatic CLT 755 Transmission With 5 Forward and 1 Reverse Speeds - AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • Front  and Rear Tires:20.5R25,
  • Grove MEGATRAK suspension,
  • Outrigger System - Hydraulic two-stage outrigger beams are extended by a single hydraulic cylinder and two cables. Outriggers can adjust to two positions: Fully extended (100%) - 27’ 3” & Partially extended (50%) - 18’ 8“. Outrigger controls are located on both sides of the carrier. An electronic level indicator is located next to each outrigger control box,
  • Clean One Owner Crane.

Location

New Mexico

Crane Details

Boom/Jib

Boom/Jib Images
Boom:
Boom: 44’-197’ Six Section Full Power Boom
Boom Length: 197'
Jib:
Jib: 43'-72' Bifold Hydraulic Swingaway Lattice Offsetable (5° - 40°) Jib, 2 - 26' Jib Inserts for a total of 125'
Jib Length: 125'
Boom/Jib Notes:
  • 44’-197’ Six Section Full Power Boom with maximum height of 207',
  • Twin Lock Boom Pin Section,
  • 43'-72' Bifold Hydraulic Swingaway Lattice Offsetable (5° - 40°) Jib,
  • 2 - 26' Jib Inserts for a total of 125' of Jib.

Carrier

Carrier images
Carrier: 10' wide Grove Carrier With 10 x 8 x 10 5 Axle Drive/Steer
Mileage:
Carrier Notes:
  • 10' wide Grove Carrier With 10 x 8 x 10 5 Axle Drive/Steer,
  • Cummins 600 water cooled 6 Cylinder turbo charged and after cooled Diesel Engine - AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • Allison Automatic CLT 755 Transmission With 5 Forward and 1 Reverse Speeds - AS PER GROVE SPECIFICATIONS AND SUBJECT TO FINAL CONFIRMATION,
  • Front  and Rear Tires:20.5R25,
  • Grove MEGATRAK suspension
  • Clean One Owner Crane.

Lifting System

Lifting System Images
Hours:
Winches: Main Winch, Auxiliary Winch
Lifting System Notes:
  • Main and Auxiliary Winches with 22mm Wire Rope,
  • Drum Rotation Indicator, 2 Speed, Load Moment Indicator with Anti-Two Block.

Hook Block/Hook Ball

Hook Block/Hook Ball Images
Hook Block/Hook Ball: Hook Block
Hook Block/Hook Ball Notes:
  • Hook Block.

Downloadable Files Associated with this Crane

Documents

Click To Enlarge or Browse

All Images

Click To Enlarge or Browse

, , , , , , ,
